Foundry Agentic Loop Workflow

A GitHub Copilot dynamic workflow that turns a brief into a verified Microsoft Foundry solution on Azure. It runs four phases in sequence:

1. Specify: EARS spec, frozen contract and deployment plan.
2. Implement: azd scaffold and provision, a hosted checkpoint, then parallel workstreams and integration.
3. Verify: local E2E, a hosted invocation, telemetry and evaluations.
4. Deploy: azd up, health checks and deployed E2E.

It ships with the foundry-agentic-loop plugin. The SDD mode of the foundry-agentic-loop skill starts it, and the Foundry Agentic Loop canvas shows its progress.

At setup, it adds the Agentic Loop SDD section to the workspace root AGENTS.md unless one exists. The section locks the workspace to SDD and routes short commands such as deploy, status and resume in later prompts. A workspace locked to rapid prototyping stops the run until Copilot converts the prototype to SDD.

One run is active per workspace. The run holds a lease in .agentic-loop/active-run.json (runId, startedAt, heartbeatAt), refreshes it with every flight record write and every five minutes, and releases it when it pauses, fails or finishes. A second run refuses to start while the lease is fresh (heartbeat under 30 minutes old) and names the active run; delete the file if that run is gone. A stale lease is taken over with a Chat line, and resuming a run takes its lease back. Every lease read-check-write runs under an exclusive .agentic-loop/active-run.lock folder, so two runs cannot both take over the same stale lease; a lock older than two minutes is left by a crash and must be deleted.

The workflow reads and writes its own files (AGENTS.md, .agentic-loop/, .agentic-loop/runs/, the record, lease and waiver files) only inside the workspace: a symbolic link on any of those paths, or a path that resolves outside the workspace, stops the run with an error instead of being followed. It never writes docs/LOOP.md itself; subagents do.

How a phase runs

Each phase follows its guide in the foundry-agentic-loop skill (references/specify.md, implement.md, verify.md or deploy.md) in fresh-context subagents, using microsoft-foundry for platform operations. Subagents stay inside the workspace, read skills from the paths resolved at setup and delete only Azure resources the run created whose provisioning failed:

• Lead: does the phase work and records lessons in docs/LOOP.md.
• Review: an independent reviewer reruns every check and reports all blocking issues at once, with evidence. Earlier reports count as claims, not evidence.
• Fix: a fixer resolves the issues, then a new review first confirms each one is resolved before finishing its checks. This repeats up to maxFixLoops times.
• Implement: the foundation step plans up to four workstreams. If they own disjoint workspace-relative files outside the shared ones the lead keeps, such as azure.yaml, infra/, docs/ and the root lockfiles, they run in parallel before integration; otherwise the build runs in sequence. Implement deploys only the hosted checkpoint services, and only when they changed; the app services deploy in Deploy.
• Ownership: before parallel workers start, overlapping or shared ownership falls back to a sequential build. After they finish, the workflow compares git status with a snapshot from before the fan-out and hands every changed path that no workstream owns to integration as an issue. It never reverts changes, and it skips the check outside a git repository.
• Retry: a subagent that ends without a report, usually after a provider error, is retried once and told to continue from the current workspace and Azure state. A second miss blocks the gate instead of spending fix loops; for a workstream worker, integration receives it as a failed workstream and finishes it.

The gate passes only on the reviewer's verdict. Reports are untrusted and fail closed: a passed report that still lists issues counts as failed, and in Verify and Deploy a passed report without evidence items ({claim, source, result}, at most 12) counts as failed with an issue asking for evidence. The gate's evidence is kept in the flight record.

Checkpoints

Each pause posts a Needs you: line in Chat that names the decision. The flight record lists every gate issue, and the canvas shows them. Resume with run_dynamic_workflow and resumeFromRunId, or from the canvas. Completed steps, including every subagent report, replay from the journal, so resuming never repeats finished work.

• Final round: a phase gets at most 20 rounds. The checkpoint after round 20 says the rounds are exhausted and that resuming ends the run; fix the root cause and start a new run, or rerun that phase alone with from and to.
• Deploy approval: approving deployment records a fingerprint in the flight record (deployApproval): the SHA-256 of .azure/deployment-plan.md, docs/spec.md and docs/verify.md, and the azd environment, subscription, location, resource group and Foundry target (AZURE_FOUNDRY_RESOURCE_GROUP, AZURE_AI_ACCOUNT_NAME, AZURE_AI_PROJECT_NAME) from .azure/<env>/.env (falling back to the args). Before every Deploy round and after every Deploy attempt, the workflow recomputes it and asks again through approve-deploy-r<n>-v1 or approve-deploy-r<n>-a<k>-v1 if anything changed, so no later step deploys and no gate passes on an unapproved change. Deploy subagents must confirm that azd env get-values and az account show match the fingerprint, and stop as blocked if they don't. A fix that needs to change an approved file or the target makes only that change, without deploying, and reports it.
• Spec approval: approving the spec records specApproval, the SHA-256 of docs/spec.md and .azure/deployment-plan.md. A gated rerun from Implement inherits it only while both still match, and otherwise asks again at approve-spec-v1, naming what changed. Before every gated Implement round, including one resumed after a pause, the workflow recomputes it and asks again at approve-spec-r<n>-v1 if either file changed. A file that is missing or cannot be read, such as a link, never matches, for spec and deploy approvals alike.
• Waivers: only a human waives a gate issue. While the run waits at blocked-<phase>-r<n>, write .agentic-loop/waivers/<runId>.json (the same file name rule as the record) as [{"issue": "<exact gate issue>", "reason": "..."}], then resume. The workflow accepts a waiver only when the file was written during that pause and the issue matches one of that checkpoint's issues, records it as waivers: [{issue, reason, approvedAt, checkpoint}], deletes the file and lists accepted waivers in that phase's later prompts. Subagents never waive issues themselves.

Workflow subagents don't appear in list_agents or read_agent. The flight record is saved when the run starts, at the first step that runs after a resume, at each gate, checkpoint, Deploy skip and other journaled event, at the result and on failure, so a quiet hour inside one Implement step is normal. Every write is tried twice. If the record still cannot be written at setup, the run fails; at a later boundary it pauses at blocked-record-<step> with the path and error instead of continuing without a record. Only the best-effort saves at the first step after a resume and on failure log a Flight record not saved line and continue. A cancelled run keeps its last saved status, so the run status from dynamic_workflows_manage (runs or inspect-run) is authoritative. The canvas Build tab shows live subagent activity.

Arguments

For an unattended run from Specify through Verify, use autonomy: "auto" and skipDeploy: true with copilot workflow run foundry-agentic-loop-workflow --args @args.json --result-file result.json, where --result-file writes only the workflow result. Such a run can still pause at a blocked-<phase>-r<n> checkpoint, and with autonomy: "gated" or without skipDeploy it also pauses for approval. The CLI has no resume command, so continue a paused run from a Copilot session with its run ID.

Limits

META.limits sets default ceilings; override them per invocation with run_dynamic_workflow limits, or raise the one that was reached when resuming a run that stopped on it.

Subagents poll long Azure operations every 30–60 seconds against an explicit deadline (20 minutes unless the phase guide sets another) and report blocked with the last status when it passes.

Outputs

• Workspace: the AGENTS.md lock, docs/spec.md, docs/implementation.md, docs/verify.md, docs/deploy.md, the lessons in docs/LOOP.md and .azure/deployment-plan.md, which alone holds the Azure settings, plus the solution itself.
• Flight record: .agentic-loop/runs/<runId>.json. A run ID that is not 1–120 characters of A-Z a-z 0-9 . _ - becomes a sanitized prefix plus the first 8 hex characters of its SHA-256, so distinct IDs never share a file. It holds status, gates (with evidence), attempts, issues, lessons, checkpoints and endpoints, plus waivers, deployApproval, ownership, rerun, skillProvenance (per skill: source kind, path, plugin version and SHA-256 of SKILL.md and the phase guides) and skillDrift (hash changes seen when a later attempt starts). Improve mode in the foundry-agentic-loop skill learns from it.
• Workspace lease: .agentic-loop/active-run.json while a run is active.
• Result: { status, runId, phases, rounds, endpoints, flightRecord }, where status is deployed, verified, or specified/implemented when to ends the run early.

Tests

node --test extensions/foundry-agentic-loop-workflow/tests/*.test.mjs

Or run npm test from extensions/foundry-agentic-loop-workflow. extension.mjs only wires lib/workflow.mjs to the SDK, and a test loads it with the SDK replaced by a stub, because the repository's root @github/copilot-sdk can be older than the runtime's. When the Foundry Agentic Loop canvas sits next to this extension, a contract test checks that it reads the workflow's Chat lines, checkpoints, flight record path and AGENTS.md section, and validates Azure args the same way.
